Overview & Relevance to Orthopaedics
Multiple myeloma (MM) is the most common primary malignancy of bone in adults over 40 years. It is a neoplasm of plasma cells (terminally differentiated B-lymphocytes) arising in the bone marrow. While myeloma is primarily managed by haematology, it frequently presents to orthopaedic surgeons with bone pain, pathological fractures, spinal cord compression, and hypercalcaemia — all requiring surgical or procedural intervention. Understanding the disease biology, the unique radiological pattern, the haematological workup, and the orthopaedic management principles is essential.
- Epidemiology: incidence approximately 6 per 100,000 per year; peak age 65–70 years; median age at diagnosis 69 years; slightly more common in males and in Black populations; 5-year survival has improved dramatically from ~25% (1990s) to ~55–60% with modern treatment (bortezomib, lenalidomide, autologous stem cell transplantation); skeletal involvement at diagnosis occurs in approximately 80% of patients
- Pathophysiology of bone destruction in myeloma: myeloma plasma cells produce RANKL and inhibit OPG (osteoprotegerin) → massive osteoclast activation → widespread lytic bone destruction; DKK-1 (Dickkopf-1) produced by myeloma cells inhibits the Wnt signalling pathway in osteoblasts → suppressed bone formation; the net result is `pure osteolysis` without any reparative new bone formation — this is why myeloma lesions are `cold` on isotope bone scan (no osteoblast activity → no new bone → no technetium uptake); DKK-1 also explains why serum alkaline phosphatase is often NORMAL or LOW in myeloma (despite extensive bone destruction) — in contrast to metastatic carcinoma where ALP is elevated
Clinical Presentation — CRAB Criteria
| CRAB Feature | Criterion | Mechanism / Details |
|---|---|---|
| C — Hypercalcaemia | Serum calcium >2.75 mmol/L (>11 mg/dL) | Osteoclast-mediated bone resorption releases calcium; hypercalcaemia causes nausea, vomiting, polyuria, polydipsia, confusion, renal impairment; treat with IV hydration + bisphosphonates (zoledronic acid) + steroids; life-threatening if severe |
| R — Renal failure | Creatinine >177 µmol/L (>2 mg/dL) | Filtered light chains (Bence-Jones proteins) precipitate in renal tubules → myeloma cast nephropathy; hypercalcaemia; amyloid deposition; NSAIDs (commonly used for bone pain) worsen renal function — use sparingly |
| A — Anaemia | Haemoglobin <100 g/L (<10 g/dL) | Marrow infiltration by plasma cells → reduced erythropoiesis; blood film shows rouleaux formation (red cells stack like coins due to elevated immunoglobulins); normochromic normocytic anaemia; ESR markedly elevated (often >100 mm/hr) — also due to elevated immunoglobulins |
| B — Bone lesions | Lytic bone lesions, osteoporosis, or pathological fracture | Vertebral collapse fractures most common (spine: 60–70% of skeletal involvement); ribs; skull (`pepper-pot skull` — multiple punched-out lytic lesions); pelvis; proximal femur; long bone lytic lesions; pathological fractures of the proximal femur and humerus are the most common orthopaedic presentations requiring surgical fixation |
- Additional SLiM-CRAB criteria (2014 International Myeloma Working Group update): S — Sixty percent or more plasma cells on bone marrow biopsy; Li — Light chain ratio ≥100 (involved:uninvolved); M — More than one focal lesion on MRI ≥5 mm; these `biomarkers of malignancy` indicate ultra-high risk smouldering myeloma requiring treatment even without CRAB symptoms
Diagnosis & Investigations
| Investigation | Findings in Myeloma | Clinical Significance |
|---|---|---|
| Serum protein electrophoresis (SPEP) | Monoclonal band (`M-band` or `M-protein`) — a narrow spike on the protein electrophoresis strip; IgG (60%) and IgA (20%) most common; IgM = Waldenström macroglobulinaemia (not myeloma); quantify the M-protein to assess tumour burden and treatment response | Cornerstone of myeloma diagnosis; presence of M-protein >30 g/L = myeloma (not MGUS); rising M-protein = disease progression or relapse |
| Urine protein electrophoresis (UPEP) / Bence-Jones protein | Free light chains (κ or λ) excreted in urine — Bence-Jones proteinuria; light chain myeloma produces only light chains (no heavy chain — SPEP may be negative); free light chain (FLC) assay on serum detects these more sensitively than urine dipstick (which misses light chains) | Bence-Jones proteins → cast nephropathy (myeloma kidney); FLC assay now standard — serum FLC ratio >100 (involved/uninvolved) = high risk (SLiM criterion) |
| Bone marrow biopsy (trephine) | Infiltration by monoclonal plasma cells; MGUS <10% plasma cells; smouldering myeloma 10–60%; myeloma >10% plasma cells + CRAB/SLiM criteria; clonal plasma cells confirm myeloma (vs reactive plasmacytosis) | Confirms diagnosis; assesses marrow involvement; required for ISS staging and treatment planning; cytogenetics (FISH) on marrow sample identifies high-risk cytogenetics (del17p, t(4;14), t(14;16)) |
| Whole-body low-dose CT (WBLDCT) | Multiple punched-out lytic lesions throughout the skeleton (skull, spine, ribs, pelvis, long bones); no sclerotic rim; no surrounding bone reaction; pathological fractures; vertebral compression fractures | Has replaced the skeletal survey (plain X-ray series) as the standard skeletal assessment in myeloma (NICE guidance, IMWG); detects lytic lesions 2–3× more than plain X-rays; guides which lesions need prophylactic fixation or radiotherapy |
| Bone isotope scan (Tc-99m MDP) | Typically NEGATIVE (`cold` scan) or falsely normal; myeloma osteolysis is pure osteoclastic resorption without osteoblast repair → no technetium uptake; bone scan is NOT the imaging of choice for myeloma | KEY EXAM FACT: bone scan is unreliable for myeloma (cold); use WBLDCT or PET-CT (FDG-PET) instead; contrast with metastatic carcinoma where bone scan is hot |
| FDG-PET/CT or whole-body MRI | PET-CT detects both focal lesions and diffuse marrow involvement; MRI is superior for spine assessment (cord compression, paraspinal extension) and diffuse marrow infiltration | PET-CT or whole-body MRI is recommended for staging and response assessment; MRI mandatory when spinal cord compression is suspected |
| Serum alkaline phosphatase (ALP) | Normal or LOW in myeloma (DKK-1 inhibits osteoblasts — no bone formation despite extensive osteolysis) | KEY EXAM FACT: ALP normal/low in myeloma despite widespread bone destruction; contrast with metastatic cancer (osteoblastic or mixed), Paget`s, and bone healing where ALP is elevated |
Orthopaedic Management
- Pathological fracture of the proximal femur: the most common orthopaedic surgical emergency in myeloma; indication for prophylactic or therapeutic intramedullary nailing or endoprosthetic replacement; intramedullary nail (cephalomedullary nail) is preferred for impending or established subtrochanteric or femoral shaft fractures — provides immediate stability and allows early weight-bearing; arthroplasty (hemiarthroplasty or total hip replacement) is preferred when the femoral head/neck is destroyed or when fracture pattern is not amenable to nailing; pre-operative radiotherapy (RT) to the lesion followed by surgical stabilisation reduces local recurrence; a critical principle: in myeloma, the ENTIRE femur should be protected if femoral fixation is performed — a nail spanning the full length protects against developing lesions elsewhere in the femur (use of a short nail leaving the distal femur unprotected risks a second pathological fracture through an unrecognised distal lesion)
- Spinal cord compression in myeloma: an oncological emergency; presents with back pain, progressive weakness, sensory loss, and urinary/bowel dysfunction; MRI of the whole spine urgently; treatment — high-dose dexamethasone immediately (reduces cord oedema and has direct anti-myeloma effect); radiotherapy to the compressing lesion (myeloma is radiosensitive — 30 Gy over 10 fractions); surgical decompression (posterior laminectomy ± anterior corpectomy ± instrumented fusion) for failure of RT, mechanical instability, or severe cord compression with rapid neurological deterioration; surgical decompression in myeloma is a palliative procedure — oncological control is the primary aim
- Vertebral augmentation — vertebroplasty and kyphoplasty: for painful vertebral compression fractures in myeloma without neurological compromise; both involve percutaneous injection of polymethylmethacrylate (PMMA) bone cement into the collapsed vertebral body under fluoroscopic guidance; kyphoplasty first inflates a balloon tamp to create a cavity and restore vertebral height before cement injection (reducing cement leakage risk compared to vertebroplasty); both procedures provide rapid and reliable pain relief; cement leakage into the spinal canal or venous system is the main risk; contraindicated when there is posterior cortex destruction with canal compromise (cement could leak into the cord)
- Bisphosphonate therapy: zoledronic acid (4 mg IV every 3–4 weeks) or denosumab (anti-RANKL monoclonal antibody) are standard for all myeloma patients with bone involvement; reduces skeletal-related events (pathological fractures, need for radiation or surgery, hypercalcaemia); osteonecrosis of the jaw (ONJ) is a recognised complication of long-term bisphosphonate therapy — dental assessment and any necessary dental work must be completed before starting bisphosphonates; invasive dental procedures should be avoided during treatment; drug holidays may be considered after 2 years of therapy
Exam Pearls
- Myeloma = most common PRIMARY bone malignancy in adults >40; plasma cell neoplasm; CRAB criteria (Hypercalcaemia, Renal failure, Anaemia, Bone lesions); IgG most common M-protein
- Bone scan is COLD (falsely negative) in myeloma — DKK-1 inhibits osteoblasts → no new bone formation → no Tc-99m uptake; use WBLDCT or PET-CT instead
- ALP normal or LOW in myeloma despite extensive osteolysis — DKK-1 mechanism; contrast with metastatic carcinoma (ALP elevated); ALP elevation in myeloma = suspect healing fracture, concurrent Paget`s, or secondary malignancy
- Rouleaux formation on blood film (red cells stack like coins — elevated immunoglobulins); markedly elevated ESR; normochromic normocytic anaemia; hypercalcaemia; elevated total protein and globulins
- WBLDCT has replaced skeletal survey — detects lytic lesions 2–3× more sensitively; NICE recommends WBLDCT for all myeloma staging; bone scan unreliable
- Proximal femoral myeloma: nail the entire femur (full-length nail) — protects against second fracture through distal unrecognised lesion; arthroplasty if head/neck destroyed; pre-op RT + surgery
- Spinal cord compression: emergency; IV dexamethasone immediately; RT (myeloma is radiosensitive); surgery for RT failure, mechanical instability, or rapid neurology deterioration
- Vertebroplasty / kyphoplasty: rapid pain relief for vertebral compression fractures; PMMA cement; kyphoplasty restores height + lower cement leak risk; contraindicated if posterior cortex destroyed with canal compromise
- Bisphosphonates: zoledronic acid standard; reduces skeletal events; ONJ complication — dental review before starting; avoid invasive dental procedures during treatment
- Pepper-pot skull on plain X-ray: multiple punched-out lytic lesions without sclerotic rim; pathognomonic of myeloma; also seen in hyperparathyroidism (brown tumours) — distinguish by clinical context and biochemistry
